Healthcare 10 minutes quote flow rates intelligent ambulance hospital equipment medical infusion pump
|
Infusion Rate
|
ml/h mode:1~1200ml/h(1ml/h step) drop/min mode:1~266drop/min(1drop/min step)
|
|
Purge Rate
|
100mh/h---1200ml/h(can be calibrated)
|
|
Flow Rate Accuracy
|
ml/h mode:Within±5%(after correct calibration) drop/min mode:Within±3%(after correct calibration)
|
|
Mechanical Precision
|
Within±2%
|
|
Maximum infusion pressure
|
150kPa
|
|
Alarm Pressure
|
High 800mmHg±200mmHg(106.7kPa±26.7kPa) Medium 500mmHg±100mmHg(66.7kPa±13.3kPa) Low 300mmHg±100mmHg(40.7kPa±13.3kPa)
|
|
Audible and Visible Alarms
|
There are bubbles,Tube is blocked,Close the door,IV set Mismatched,Battery running out,Infusion finish,Equipment
failure,Abnormally Operation,Software Exception,Low battery, forget the operations etc
|
|
Transport&Storage Condition
|
Temperature -20ºC~+55ºC Relative Humidity £95% Atmospheric Pressure 50.10KPa---106.0KPa
|
|
Infusion Set
|
Compatible with any brand of infusiong sets ater correct calibration The following brands of infusiong sets are
recommended:GEA,Onemed,SHINVA
|
|
Infusion maximum value (under single fault condition)
|
1ml
|
|
Forbidden
|
Not support blood Infusion
|
|
Dimension
|
140mm(L)´157mm(W)´220mm(H)
|
|
Net Weight
|
1.8kg
|
|
Package Reference
|
1pc Carton:2.8KG,33cm(L)×28cm(W)×26cm(H)
2pcs Carton:6.5KG,52cm(L)×30cm(W)×36cm(H)
3pcs Carton:9.6KG,76cm(L)×30cm(W)×36cm(H)
|
